PVC Playhouse & Sunshade: Fabric Requirements and Cuts

PVC Playhouse Tent Collage

I hope everyone enjoyed a happy 4th of July!

Now that you have your PVC frame constructed, we can move on to the next step – gathering your fabrics and making the cuts.



PVC Playhouse Tent 3

Fabric requirements:
All fabrics are 60″ wide with the exception of the Swiss dot floral on the curtains.  If you choose fabrics which aren’t as wide or are directional, you may need additional yardage.

Walls: duck cloth cotton canvas – 5 yards.  If you don’t want to piece the rectangles in the front then you’d need an additional 3/4 of a yard.
Roof: reusable shopping bag fabric – 2 1/3 yards
Awnings: home decor fabric – 1 1/4 yards
Curtains: lightweight cotton – 1 yard
Window trims: double fold bias tape – 2- 3 yard packages twill tape or cotton webbing – 3 yards

Main cuts:
Side walls: two cuts 47″ x 60″(full width)
Back wall: 78″ x 60″ then fold the fabric in half lengthwise and cut 45″ angle to the peak
Front peak: sew the two cutoffs from the back wall together.



PVC Playhouse Tent 2

Press the seam open and then tuck the raw edges into the seam and stitch down close to each edge.

Front awning: 14″ x 60″
Side awnings: 2 cuts 16″ x 32″
Curtains: 4 cuts 18″ x 22.5″ (1 yard quartered)

Next up is how to make the windows including how to make the mitered corners for the square bindings and sewing and installing the curtains and awnings.
